Washers
003.20.041
Available immediately
| Unit price | Quantity |
|---|---|
|
€4.60*
/
100
PCS
|
from 100 |
Available immediately
003.04.013
Available immediately
| Unit price | Quantity |
|---|---|
|
€3.95*
/
100
PCS
|
from 100 |
Available immediately
003.20.049
Available immediately
| Unit price | Quantity |
|---|---|
|
€8.30*
/
100
PCS
|
from 100 |
Available immediately
003.20.031
Available immediately
| Unit price | Quantity |
|---|---|
|
€4.15*
/
100
PCS
|
from 100 |
Available immediately
003.03.031
Available immediately
| Unit price | Quantity |
|---|---|
|
€6.75*
/
100
PCS
|
from 100 |
Available immediately
003.03.036
Available immediately
| Unit price | Quantity |
|---|---|
|
€2.00*
/
100
PCS
|
from 100 |
Available immediately
003.04.043
Available immediately
| Unit price | Quantity |
|---|---|
|
€3.80*
/
100
PCS
|
from 100 |
Available immediately
003.04.033
Available immediately
| Unit price | Quantity |
|---|---|
|
€3.75*
/
100
PCS
|
from 100 |
Available immediately
003.09.542
Available immediately
| Unit price | Quantity |
|---|---|
|
€4.75*
/
100
PCS
|
from 100 |
Available immediately
003.42.031
Available immediately
| Unit price | Quantity |
|---|---|
|
€1.70*
/
100
PCS
|
from 100 |
Available immediately
003.20.059
Available immediately
| Unit price | Quantity |
|---|---|
|
€7.55*
/
100
PCS
|
from 100 |
Available immediately
003.09.248
Available immediately
| Unit price | Quantity |
|---|---|
|
€30.75*
/
500
PCS
|
from 500 |
Available immediately
003.20.051
Available immediately
| Unit price | Quantity |
|---|---|
|
€6.00*
/
100
PCS
|
from 100 |
Available immediately
003.01.041
Available immediately
| Unit price | Quantity |
|---|---|
|
€1.15*
/
100
PCS
|
from 100 |
Available immediately
003.20.024
Available immediately
| Unit price | Quantity |
|---|---|
|
€9.35*
/
100
PCS
|
from 100 |
Available immediately
003.44.067
Available immediately
| Unit price | Quantity |
|---|---|
|
€9.25*
/
100
PCS
|
from 100 |
Available immediately
003.20.061
Available immediately
| Unit price | Quantity |
|---|---|
|
€6.20*
/
100
PCS
|
from 100 |
Available immediately
003.05.031
Available immediately
| Unit price | Quantity |
|---|---|
|
€0.90*
/
100
PCS
|
from 100 |
Available immediately
003.04.023
Available immediately
| Unit price | Quantity |
|---|---|
|
€4.45*
/
100
PCS
|
from 100 |
Available immediately
003.72.051
Available immediately
| Unit price | Quantity |
|---|---|
|
€34.25*
/
500
PCS
|
from 500 |
Available immediately
003.20.069
Available immediately
| Unit price | Quantity |
|---|---|
|
€12.60*
/
100
PCS
|
from 100 |
Available immediately
003.06.631
Available immediately
| Unit price | Quantity |
|---|---|
|
€1.45*
/
100
PCS
|
from 100 |
Available immediately
003.31.513
Available immediately
| Unit price | Quantity |
|---|---|
|
€32.90*
/
100
PCS
|
from 100 |
Available immediately
003.03.026
Available immediately
| Unit price | Quantity |
|---|---|
|
€4.20*
/
100
PCS
|
from 100 |
Available immediately
Washers are mechanical or “non-electrical” parts that are often used in electronics production for PCB assembly. They are an essential part of almost every parts list and are used in prototypes, small-series and large-series production, generally in combination with other connection and fastening components. They also have a diverse range of applications in mechanical engineering as well as in the automotive industry, transport technology, communication technology and medical devices.
Washers are predominantly standard parts, which are usually manufactured in the metal industry in large quantities by punching or turning. In addition, they might also be heat treated to harden the steel or they may be surface treated to improve durability, for example by using electroplating to increase corrosion resistance. Plastic washers are manufactured using the injection molding process.
Washers are available in numerous designs
Our product range includes a large variety of washers in standard designs as well as compatible screws, fasteners and nuts. In addition, we also offer the option of custom production and made-to-order parts. As you would expect, we are also experts in large-series production. Please do not hesitate to contact us!
Our range of washers includes the following standard models in a variety of designs to DIN, ISO, and UNC standards – we have large quantities available immediately from stock:
- Flat washers
- Rosette washers
- Lock washers
- Sealing washers
- Connecting washers
- Clamping washers and strut channel washers
- Spring washers
- Retaining rings
In addition to our range of standard washers, we also supply self-retaining washers, self-adhesive washers, contact washers, serrated washers, tooth lock washers, conical spring washers, large-diameter washers, split lock washers and many more. In addition, we offer SEMS screws with pre-mounted washers that are ready for immediate mounting and therefore save you time during the assembly process.
In the ETTINGER online shop, you can buy washers in the following materials depending on the model:
- zinc-plated, nickel-plated or burnished steel
- stainless steel (rustproof) A1, A2 and A4
- aluminum
- nickel-plated brass
- polyamide (PA) natural or black
- polyamide (PA) with 30% glass fiber
- polyvinylidene fluoride (PVDF) natural
- polyethylene (PE) soft
- polyoxymethylene (POM) black, red or natural
- Teflon
- laminated paper, fiber or vulcanized fiber
Most of our washers for screws are made of steel and have an inside diameter of 2.2 mm to 13 mm, an outside diameter of 4 mm to 23 mm and a thickness of 0.3 mm to 5 mm. Steel washers are divided into different strength grades using the numbers 4.6, 8.8 and 12.9. This makes it very easy to determine their tensile strength (first number; 4.6) and yield strength (second number; 4.6).
For use in corrosive environments, stainless steel is also worth considering in addition to brass and plastic. The most commonly used stainless steel grades for washers are A2 and A4. The A stands for austenitic steels, which have excellent ductility, resilience, and corrosion resistance. The number indicates the type of steel. A2 is used as standard, whereas A4 stainless steel washers are used, for example, in coastal regions because of the high salt content in the air. A4 washers are also used in areas near chlorinated water (which contains acid) and in the food and chemicals industries. Order you chosen washer designs easily online, even in high quantities!
In contrast to stainless steel washers, a protective coating is required on normal steel washers if they are used in corrosive conditions. We offer different surface treatment finishing processes.
Our services – washers that meet your requirements
- Surface finishing: electroplating in line with DIN EN ISO 4042 or chemical coatings
- Custom production from drawings
- Screw and washer assemblies
- Set assembly
Quality from ETTINGER – your requirements are our mission
For more than 60 years we have been supplying fasteners and electromechanical components in accordance with widely recognized standards. We rely on qualified employees, strict incoming goods inspections and innovative technologies to ensure that we consistently meet our high quality standards for battery and soldering technology as well as other electromechanical accessories.
At ETTINGER, we prefer to manufacture and source our parts in Germany. Thanks to long-standing, reliable business relationships with our suppliers we now have strong partners at our side, which in turn enable us to offer you products of the highest quality.
Quality through service and expertise. When you buy components from ETTINGER, you can enjoy peace of mind and confidence in your project.
